Cable Concepts Plenum LVT Wire 18AWG 2 C. FT6, CUL, UTP, CMP, 1000 Ft. White
WICH6000WH
We currently have 34 in stock.
Details
Cable Concepts LVT Wire 18AWG 2 Conductor, Plenum, FT6, CUL, UTP, CMP, 1000 Ft. White
This cable can be used both indoor and outdoor, isĀ (FT6) fire rated, but is NOT suitable for burial. This cable is Plenum, FT6, CUL, UTP, CMP approved.
Application: Used for power limited circuits such as thermostat, air conditioning and heatingĀ controls, heat pumps, bell and alarm systems, signal systems, intercom systems, door bells,Ā remote control units where maximum voltage does not exceed 30 Volts.
| Ā 1) Description |
| 18 Gauge, 2 Conductor solid bare copper, 0.010 |
| Plenum, FT6, CUL, UTP, CMP |
| 2) Physical Dimensions | |
| Center Conductor: | 1.02+0.01mm BC |
| Insulation: | 1.53+0.02mm PVC |
| Thickness: | 0.255mm |
| Color Code: | Black & Red |
| Jacket: | 3.96+0.05mm PVC |
| Thickness: | 0.45mm |
| 3) Mechanical Characteristics | |
| Operating Temperature Range: | 20 To +75 |
| Installation Temperature Range: | 0 To +60 |
| Ā Voltage Rating: | 30V |
| Capacitance: | 26 pF/ft |
| DCR: | 6.385 phms/1000ft @ 68Ā°F |
